12283

Reach: 0.280"

12283

Seamless compression seals are nearly 100% closed cell to prevent water from penetrating foam cell structure. Extruded skin provides a unique UV resistant barrier with design features that enhance the weather strip's sealing performance. All of Foam-Tite®'s products are CFC and phthalate free.



product highlights

  • Overall Reach:  .280" (7.11mm)
  • Bulb Diameter:  .192" (4.88mm)
  • Kerf Depth:  .230" (5.84mm)
  • Kerf Width:  .125" (3.18mm)


Specifications

Part # Box Quantity Cut Length Recommended Opening Reach Backing / Kerf Width
12283132091500 3000' Reeled 0.100" 0.280" 0.125"

Blacks

Black
Black
